Pulsar Wing Main Image
3PH Rotary Cutter - Wing

New for 2017, MK Martin presents the Wing. Available in a 15' model, the three triple blade assemblies make short work of stubble whether in the pasture, field, or brush. Each wing can independently float 20° in either direction to conform to the contours of the ground. The 15' width of the cutter can be greatly reduced by folding up both hydraulic wings to better transport from one field to another, and to store the cutter in tight spaces.


Features & Options

  • 15' dual wing rotary cutter
  • 4 heavy duty gearboxes, each covered with limited 5 year warranty
  • Transport lock for each wing
  • 1.5" diameter cutting capacity
Model PW180
Shipping Weight (LBS.) 4,400
3PH Mount Draw Bar Hitch
Cutting Height 3"-15"
Cutting Path 180"
Max Brush Diameter 1.5"
Overall Width (Wings Down) 184"
Folded Width (Wings Up) 78"
Tip Speed (Ft/Min) 15,100 ft/min on Wings
14,850 ft/min on center
Wheels (Pneumatic) 21"
Blades 9 blades 1/2"x4"
Tractor HP (min) 75HP
PTO RPM 540
Gearbox Rating (Wing) 140 HP
Gearbox Rating (Center) 105 HP
Gearbox Rating (Divider) 87 HP
Deck 3/16"
Stump Jumper Yes
Protection Independent Slip Clutch on Each Spindle
Pneumatic Wheels Feature Image

Pneumatic Wheels

Contour Cutting Feature Image

20° Contour Cutting

Gearbox Feature Image

Gearbox

Chain Guard Feature Image

Standard Chain Curtain

Blade Assembly Feature Image

3 Blade Assembly

Steel Blade Guard Feature Image

Steel Blade Guard

Transport Lock Feature Image

Transport Lock
